PVC Pipe Threader

PVC Pipe Threading Machine by Industrial Machinery Corporation

PVC Pipe Threading Machine by Industrial Machinery Corporation thumbnail

PVC Pipe Threading Machine by Industrial Machinery Corporation additional view 1

PVC Pipe Threading Machine by Industrial Machinery Corporation additional view 2

PVC Pipe Threading Machine by Industrial Machinery Corporation additional view 3

PRICE & QUOTATION

Starting From US$ 4,000

Choose options

Set quantity

Request quotation

Select the required model and specifications to request your quotation.

Get quotation WhatsApp Call now Enquire now

Review PVC Pipe Threader for your component and the required production operation.

Prepare a job-specific equipment enquiry

IMC can review a configuration to cut the specified external thread on suitable PVC pipe with a compatible threading setup against your component requirements. Send a drawing or sample and state PVC grade, outside diameter, wall thickness, pipe length and mating thread drawing. Distinguish the required operation from other stages in the workshop so the offer identifies the equipment actually needed.

Confirm the working configuration

The technical discussion should address pipe support, clamping pressure, compatible chasers and clearance at the pipe end. Ask for the included tool package and accessories to be identified against the drawing rather than relying only on a product name. PVC pipe selection must consider wall thickness and the required connection, as well as nominal pipe size. Include the intended batch mix and how the workpiece will be loaded, supported and inspected.

Specify delivery and acceptance

Agree the component checks for thread depth, fitting engagement and the condition of the PVC wall after cutting. Confirm the destination and available electrical supply, together with any packing, spare-tool or commissioning needs. Delivery and service terms should be agreed in the offer. Review the model data below and add the selected configuration and quantity to the Quote List so those options accompany the enquiry.

Information to send with your enquiry

PVC grade
Outside diameter
Wall thickness
Pipe length and mating thread drawing

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Diameter of the job

Thread Length Require

Thread Type

Purchase

Expected Price

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

The PVC Pipe Thread Cutting Machines are used to cut the external threads with the help of a Tangential chaser. Chaser is used as a cutter in the machines. It remains still, Die-head rotates and different types of threads can be cut parallel and taper such as BSPT, BSW, BSP, NPT, UNF, METRIC, UNC, ACME, and BSF Threads. The Machine mainly consists of the following:-

Base
Head Stock
Saddle
Bed or Pillar Type Clamping Vice
Die Head.

PVC Pipe Thread Cutting Machine

Model	3/8" to 2" (10MM to 50MM)	1/2" to 2.1/2" (12MM to 65MM)	1" to 4" (25MM to 100MM)	2.½" to 6" (65MM to 150MM)	4" to 8" (100MM to 200MM)	8" to 10" (200MM to 250MM)
Saddle Movement	10"- 12"	16"	10“ - 12"	8"	8"	8"
Spindle Speed Range	127-180	60-90-120	40-75-115	25-50	25-50	10-20-30
Number of Spindle Speed	2	3	3	2	2	3
Threading Capacity	3/8" to 2"	1/2" to 2.1/2"	1 to 4"	2.1/2" to 6"	4" to 8"	8" to 10"
Production per Hour	100-120	70-90	35-40	20-25	15-20	15-20
H.P. Required	3 H.P.	7.5 H.P.	12.5 H.P. 960	15 H.P. 960	20 H.P. 960	30 H.P. 960
Lead Screw	Provided	Provided	Provided	Provided	Provided	Provided
Weight (KG) Approx.	550	990	1600	1900	2500	5000

Frequently Asked Questions About PVC Pipe Threading Machine

Why discuss PVC grade, wall thickness and joint drawing before ordering pvc pipe threading machine?

Those details define the application that the equipment must accommodate. The pipe must be held without unacceptable deformation, and the cutting tools must suit the material and thread. Share the actual pipe dimensions for review.

How do I build an enquiry for the pvc pipe threading machine shown here?

Select the listed machine options, add the required quantity and attach your application notes. State PVC grade, wall thickness and joint drawing, together with the intended output and delivery location, so the quotation addresses your actual production task.

What does the pvc pipe threading machine do within a production setup?

PVC threads are cut with holding and tooling appropriate to the plastic pipe wall and joint. Its role should be considered alongside the preceding preparation and subsequent inspection or assembly steps. The technical table and working videos provide a starting point for that discussion.
