Portable Pipe and Bolt Threader

Portable Pipe And Bolt Threading Machine by Industrial Machinery Corporation

Portable Pipe And Bolt Threading Machine by Industrial Machinery Corporation thumbnail

Review Portable Pipe and Bolt Threader for your component and the required production operation.

Prepare a job-specific equipment enquiry

IMC can review a configuration to prepare external threads on compatible pipe and bolt workpieces with appropriate threading tools against your component requirements. Send a drawing or sample and state pipe and bolt sizes, materials, thread forms, lengths and site utilities. Distinguish the required operation from other stages in the workshop so the offer identifies the equipment actually needed.

Confirm the working configuration

The technical discussion should address the separate tooling required for pipe and bolt jobs, holding arrangements and size changeovers. Ask for the included tool package and accessories to be identified against the drawing rather than relying only on a product name. List pipe and bolt work separately so that the quotation identifies the dies and accessories for each application. Include the intended batch mix and how the workpiece will be loaded, supported and inspected.

Specify delivery and acceptance

Agree the component checks for the pipe connection thread and bolt thread against their respective drawings. Confirm the destination and available electrical supply, together with any packing, spare-tool or commissioning needs. Delivery and service terms should be agreed in the offer. Review the model data below and add the selected configuration and quantity to the Quote List so those options accompany the enquiry.

Information to send with your enquiry

Pipe and bolt sizes
Materials
Thread forms
Lengths and site utilities

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Thread Type

Purchase

Min And Max Diameter of the Job

Expected Price

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

We offer well designed Portable Pipe and Bolt Threading Machine all over the world. We are recognized as trustworthy Electric Pipe and Bolt Threading Machine Suppliers, Manufacturers, and Exporters in India. The Portable Pipe and Bolt Threading Machine we offer is known for superior efficiency and durability. These are available at pocket-friendly prices.

Portable Pipe and Bolt Threading Machine

Model No.	IMC-PPBTM-1/2" to 2"
Sizes for Pipe (Inches)	1/2" to 2"
Sizes for Bolts	3/8" - 2 & 10 MM - 33MM
Sizes for Conduits	1/2" - 2 & 12MM - 30 MM
Specifications	230V/50 Hz., 750W, 27 RPM
Die-Head(Inch.)	1/2" - 2
Dies Including (Inch.) BSPT or NPT	1/2" - 3/4" & 1 - 2"
Approx. Wt. of the Machine	62 Kgs.

Frequently Asked Questions About Portable Pipe And Bolt Threading Machine

Why discuss site supply and the pipe and bolt ranges before ordering portable pipe and bolt threading machine?

Those details define the application that the equipment must accommodate. Do not assume it can. Identify both thread standards and ask which die heads, dies and accessories cover the planned jobs.

How do I build an enquiry for the portable pipe and bolt threading machine shown here?

Select the listed machine options, add the required quantity and attach your application notes. State site supply and the pipe and bolt ranges, together with the intended output and delivery location, so the quotation addresses your actual production task.

What does the portable pipe and bolt threading machine do within a production setup?

Portable equipment combines pipe and bolt threading capability in a format suited to moving between jobs. Its role should be considered alongside the preceding preparation and subsequent inspection or assembly steps. The technical table and working videos provide a starting point for that discussion.
