Pipe Facing Machine

Pipe End Facing Machine by Industrial Machinery Corporation

Pipe End Facing Machine by Industrial Machinery Corporation thumbnail

Review Pipe Facing Machine for your component and the required production operation.

Prepare a job-specific equipment enquiry

IMC can review a configuration to prepare pipe ends through the specified facing, chamfering or deburring operation against your component requirements. Send a drawing or sample and state pipe material, diameter, wall thickness and the finished end-profile drawing. Distinguish the required operation from other stages in the workshop so the offer identifies the equipment actually needed.

Confirm the working configuration

The technical discussion should address cutters, pipe holding, end location and access to the surfaces being prepared. Ask for the included tool package and accessories to be identified against the drawing rather than relying only on a product name. Show the required end profile clearly; facing, chamfering and deburring are related but distinct operations. Include the intended batch mix and how the workpiece will be loaded, supported and inspected.

Specify delivery and acceptance

Agree the component checks for face geometry, chamfer dimensions where required and removal of unwanted burrs. Confirm the destination and available electrical supply, together with any packing, spare-tool or commissioning needs. Delivery and service terms should be agreed in the offer. Review the model data below and add the selected configuration and quantity to the Quote List so those options accompany the enquiry.

Information to send with your enquiry

Pipe material
Diameter
Wall thickness and the finished end-profile drawing

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Min And Max Diameter of the Job

Maximum Length Required

Expected Price

Purchase

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

VIDEO REFERENCE

Machine Videos Gallery

No product-specific playlist is stored for this item yet. View IMC machine demonstrations and production videos in the main gallery.

View Machine Videos

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

With the help of our engineers we develop superb quality Pipe end facing machine, we are the perfect destination for you. We present pipe facing machines that are widely used in large number of industries for the purpose of Chamfering and Deburring of Pipe, even before the galvanizing and threading operation.

The Pipe End Facing Machine is used for the function of Chamfering and Deburring the Pipe before the galvanizing and threading operation. The Pipe is chamfered from the Outer, Inner, and Front face by three different tools. The Pipe remains Stationery and the Facing Head rotates. Slide Travels towards Facing Head for Chamfering manually. We are counted among the prominent Tube End Facing Machine Suppliers In India and we also export our products. We offer such machines at reasonable prices.

Consists Of

Bed
Head Stock
Clamping Vice
Saddle

Specifications:

Model No.	IMC-EM- 1/2" to 1.1/2"	IMC-BM-1/2" to 4"
Min. Dia of Pipe to be Chamfered	1/2" N.B. Pipe	1/2"
Max. Dia of Pipe to be Chamfered	1.1/2"	4"
Cutting Tools Required (HSS 10% Cobalt)	3/8"	3/8"
Number of Spindle Speeds	Two nos.	Four nos.
Range of Spindle Speeds	37 to 64 RPM	68 to 180 RPM
Main Motor	3 H.P. 1440 RPM	3 H.P. 1440 RPM
Approx. Wt. of the Machine	750 Kgs.	1100 Kgs

Frequently Asked Questions About Pipe End Facing Machine

Why discuss pipe dimensions and end-face requirements before ordering pipe end facing machine?

Those details define the application that the equipment must accommodate. Yes. State whether a square face, bevel or another profile is required. Confirm which end-preparation operations the proposed configuration includes.

How do I build an enquiry for the pipe end facing machine shown here?

Select the listed machine options, add the required quantity and attach your application notes. State pipe dimensions and end-face requirements, together with the intended output and delivery location, so the quotation addresses your actual production task.

What does the pipe end facing machine do within a production setup?

Pipe ends are faced to prepare a defined end surface before joining or further machining. Its role should be considered alongside the preceding preparation and subsequent inspection or assembly steps. The technical table and working videos provide a starting point for that discussion.
