Base Jack Welding Machine

Base Jack Welding Machine by Industrial Machinery Corporation

Base Jack Welding Machine by Industrial Machinery Corporation thumbnail

Review Base Jack Welding Machine for your component and the required production operation.

Prepare a job-specific equipment enquiry

IMC can review a configuration to join suitable scaffolding jack components to the specified plate or U-shaped support against your component requirements. Send a drawing or sample and state jack type and dimensions, plate or U-base geometry and the weld drawing. Distinguish the required operation from other stages in the workshop so the offer identifies the equipment actually needed.

Confirm the working configuration

The technical discussion should address component clamping, rotation arrangement and tooling for the chosen jack form. Ask for the included tool package and accessories to be identified against the drawing rather than relying only on a product name. Solid and hollow jack assemblies should be identified separately so their holding fixtures and joint requirements can be reviewed. Include the intended batch mix and how the workpiece will be loaded, supported and inspected.

Specify delivery and acceptance

Agree the component checks for jack alignment, base orientation and the required weld inspection. Confirm the destination and available electrical supply, together with any packing, spare-tool or commissioning needs. Delivery and service terms should be agreed in the offer. Review the model data below and add the selected configuration and quantity to the Quote List so those options accompany the enquiry.

Information to send with your enquiry

Jack type and dimensions
Plate or U-base geometry and the weld drawing

To review your application, send IMC your component drawing and requirements. You can also compare related machines and tooling in the product range.

VIEW SPECIFICATIONS

Available options

Select the required options and add this machine to your quotation.

Available Options

Purchase

Min And Max Diameter of the Job

Maximum Length Required

Expected Price

Your selected configuration is stored in the existing Quote List flow for review before enquiry.

Product Videos

View full playlist on YouTube

Scaffolding Prop Nut Cup Handle Welding Machine

Scaffolding Prop Nut Cup Handle Welding Machine Manufacturer & Exporter

Scaffolding Prop Nut Cup Handle Welding Machine - IMC

TECHNICAL DATA

Technical Specifications

Model data and technical details supplied for this product. Final configuration can be confirmed against your application.

We are fulfilling the varied requirements of clients by manufacturing and exporting optimum quality Base Jack Welding Machine. Base Jack Welding Machine is widely used to weld base plate with pipe without making any joint between them. It gives high production and accuracy to the product. Base jack welding machines weld solid jacks, Tie rods, Hollow jacks with the base plate. Base jack is used with the combination of Cuplock welding to make a structure. All the components are used in combination with each other Base jack welding machine, Inner prop welding machine, Outer prop welding machine, Cuplock welding machine, Ringlock welding machine. We provide our clients with a comprehensive range of Base Jack Welding Machine, which is dimensionally accurate and wear & tear resistant. These are corrosion resistant and manufactured as per the standards recommended by regulatory bodies. Available in various specifications, these can also be customized as per the requirements of our clients.

Base jack welding machine is designed to increase production and quality of welding on solid threaded bar and hollow threaded pipes with base plate of any size and shape and u-base of any size and shape, however the machine has the capability to weld up to 1200 pieces in 10 hours of working shift , there is no need to make welding tag pipe or solid with base plate and u-base, on the other hand, machine has the adjustments if any ovality comes in job. suitable for the length 300mm to 1000mm and sizes from 28mm to 48mm, length adjustment with the screw drive.

Base Jack Welding Machine Specifications :

Electric Supply		Single Phase 220 – 10 % Volts Frequency HZ 50/60
Speed		2 to 10 RPM
Motor Drive		75 C
Motor Type		DC
Torch Clamping		PNEUMATIC
Length Adjustment		Up to 1000 mm
Dimension		L x W x H 5.4×2.5×4.7 (Foot)

Frequently Asked Questions About Base Jack Welding Machine

Why discuss plate, stem and joint dimensions before ordering base jack welding machine?

Those details define the application that the equipment must accommodate. Give the plate size, stem dimensions and weld location. Alignment and access to the joint should be considered alongside production requirements.

How do I build an enquiry for the base jack welding machine shown here?

Select the listed machine options, add the required quantity and attach your application notes. State plate, stem and joint dimensions, together with the intended output and delivery location, so the quotation addresses your actual production task.

What does the base jack welding machine do within a production setup?

Base-jack components are held in position for the required welded joint. Its role should be considered alongside the preceding preparation and subsequent inspection or assembly steps. The technical table and working videos provide a starting point for that discussion.
